    Why  mission mars .. from Space X  - Page 1
    1/61
    WHY GO ANYWHERE?
    2/61
    Why  mission mars .. from Space X  - Page 3
    3/61
    WHY MARS?
    4/61
    HUMANITY’S GREATEST ADVENTURE
Credit: Roberto Ziche, NASA, planetpixelemporium.com, planetscapes.com
    5/61
    Why  mission mars .. from Space X  - Page 6
    6/61
    Why  mission mars .. from Space X  - Page 7
    7/61
    FROM EARLY EXPLORATION TO A SELF-SUSTAINING CITY ON MARS
    8/61
    COST OF TRIP TO MARS
=
INFINITE MONEY
WANT TO GO CAN AFFORD TO GO
NOW
    9/61
    COST OF TRIP TO MARS
=
$10 BILLION / PERSON
WANT TO GO CAN AFFORD TO GO
USING TRADITIONAL METHODS
    10/61
    COST OF TRIP TO MARS
=
MEDIAN COST OF A HOUSE IN THE UNITED STATES
WANT TO GO CAN AFFORD TO GO
WHAT’S NEEDED
    11/61
    IMPROVING COST PER TON TO MARS BY FIVE MILLION PERCENT
    12/61
    RIGHT PROPELLANT
FULL REUSABILITY
REFILLING IN ORBIT
PROPELLANT PRODUCTION ON MARS
    13/61
    FULL REUSABILITY
    14/61
    To make Mars trips possible on a large-enough scale to
create a self-sustaining city, full reusability is essential
    15/61
    Boeing 737
Price
Passenger Capability
Cost/Person - Single Use
Cost/Person - Reusable
Cost of Fuel / Person
$90M
180 people
$500,000
$43 (LA to Las Vegas)
$10
    16/61
    REFILLING IN ORBIT
    17/61
    Not refilling in orbit would require a
3-stage vehicle at 5-10x the size and cost
Spreading the required lift capacity across
multiple launches substantially reduces
development costs and compresses schedule
Combined with reusability, refilling makes
performance shortfalls an incremental rather
than exponential cost increase
    18/61
    PROPELLANT ON MARS
    19/61
    Allows reusability of the ship and
enables people to return to Earth easily
Leverages resources readily available on Mars
Bringing return propellant requires approximately
5 times as much mass departing Earth
    20/61
    RIGHT PROPELLANT
    21/61
    HYDROGEN/OXYGEN
H2 /O2
VEHICLE SIZE
COST OF PROP
REUSABILITY
MARS PROPELLANT PRODUCTION
PROPELLANT TRANSFER
GOOD
DEEP-CRYO METHALOX
CH4 /O2
OK
BAD
VERY BAD
KEROSENE
C12H22.4 /O2
    22/61
    RIGHT PROPELLANT
FULL REUSABILITY
REFILLING IN ORBIT
PROPELLANT PRODUCTION ON MARS
    23/61
    TARGETED REUSE PER VEHICLE
1,000 uses per booster
100 per tanker
12 uses per ship
SYSTEM ARCHITECTURE
    24/61
    VEHICLE DESIGN AND PERFORMANCE
    25/61
    Carbon-fiber primary structure
Densified CH /O2 propellant
Autogenous pressurization
4
    26/61
    VEHICLES
BY PERFORMANCE
    27/61
    VEHICLES
BY PERFORMANCE
    28/61
    Why  mission mars .. from Space X  - Page 29
    29/61
    RAPTOR ENGINE
    30/61
    Cycle
Oxidizer
Fuel
Chamber Pressure
Throttle Capability
Full-flow staged combustion
Subcooled liquid oxygen
Subcooled liquid methane
300 bar
20% to 100% thrust
Sea-Level Nozzle
Expansion Ratio: 40
Thrust (SL): 3,050 kN
Isp (SL): 334 s
Vacuum Nozzle
Expansion Ratio: 200
Thrust: 3,500 kN
Isp: 382 s
    31/61
    ROCKET BOOSTER
    32/61
    Length                  77.5 m
Diameter                        12 m
Dry Mass                         275 t
Propellant Mass            6,700 t
Raptor Engines    �          42
Sea Level Thrust           128 MN
Vacuum Thrust              138 MN
Booster accelerates ship to staging velocity, traveling 8,650 km/h
(5,375 mph) at separation
Booster returns to landing site, using 7% of total booster prop load
for boostback burn and landing
Grid fins guide rocket back through atmosphere to precision landing
    33/61
    Engine configuration
Outer ring: 21
Inner ring: 14
Center cluster: 7
Outer engines fixed in place
Only center cluster gimbals
    34/61
    INTERPLANETARY SPACESHIP
    35/61
    Length
Max Diameter
Raptor Engines

Vacuum Thrust
Propellant Mass
Dry Mass
Cargo/Prop to LEO

Cargo to Mars
49.5 m
17 m
3 Sea-Level - 361s Isp
6 Vacuum - 382s Isp
31 MN
Ship: 1,950 t
Tanker: 2,500 t
Ship: 150 t
Tanker: 90 t
Ship: 300 t
Tanker: 380 t
450 t (with transfer on orbit)
Long term goal of 100+ passengers/ship
    36/61
    SHIP CAPACITY WITH FULL TANKS
    37/61
    ARRIVAL
From interplanetary space, the ship enters the atmosphere, either
capturing into orbit or proceeding directly to landing
Aerodynamic forces provide the majority of the deceleration,
then 3 center Raptor engines perform the final landing burn
Using its aerodynamic lift capability and advanced heat shield
materials, the ship can decelerate from entry velocities in excess
of 8.5 km/s at Mars and 12.5 km/s at Earth
G-forces (Earth-referenced) during entry are approximately 4-6 g’s
at Mars and 2-3 g’s at Earth
Heating is within the capabilities of the PICA-family of heat shield
materials used on our Dragon spacecraft
PICA 3.0 advancements for Dragon 2 enhance our ability to use the heat
shield many times with minimal maintenance
    38/61
    PROPELLANT PLANT
    39/61
    First ship will have small propellant plant, which will be expanded over time
Effectively unlimited supplies of carbon dioxide and water on Mars
5 million cubic km ice
25 trillion metric tons CO2
    40/61
    COSTS
    41/61
    FUNDING
Steal Underpants
Launch Satellites
Send Cargo and Astronauts to ISS
Kickstarter
Profit
    42/61
    TIMELINES
    43/61
    2002
    44/61
    Why  mission mars .. from Space X  - Page 45
    45/61
    FUTURE
    46/61
    NEXT STEPS
    47/61
    RED DRAGON
    48/61
    Mission Objectives
Learn how to transport and land large payloads on Mars
Identify and characterize potential resources such as water
Characterize potential landing sites, including identifying surface hazards
Demonstrate key surface capabilities on Mars
    49/61
    RAPTOR FIRING
    50/61
    Why  mission mars .. from Space X  - Page 51
    51/61
    CARBON FIBER TANK
    52/61
    Why  mission mars .. from Space X  - Page 53
    53/61
    Why  mission mars .. from Space X  - Page 54
    54/61
    Why  mission mars .. from Space X  - Page 55
    55/61
    Why  mission mars .. from Space X  - Page 56
    56/61
    BEYOND MARS
    57/61
    JUPITER
    58/61
    ENCELADUS
    59/61
    EUROPA
    60/61
    SATURN
    61/61
